    Hot bar Bonding machine - Hot bar Bonding machine Manufacturers, Suppliers and Exporters on pcbcutting.com Electronics Production Machinery-YSHP-1A
    Detailed Product Description

    Hot Bar Bonding machine-YSHP-1A
    1.Closed Loop PID temperature control with visible LCD display.
    2.LCD display programmable pressure switch for precise force control.
    3.Each heating cycle is triggered by a real time pressure sensor.
    4. Floating thermode ensures consistent pressure and heat transfer between
    thermode head and the parts to be joined.
    5. Silicon rubber can be fitted in bonding Heat Seal Connectors between LCD
    and PCB.
    6.Standard workpiece holder is mounted on a linear guideway and designed
    to allow for easy changeover and repeatable operation.
    7. Parts registration is adjusted by micrometer and secured by vacuum lock.
    Optional CCD system for fine pitch component.


    Specification:



    Size


    550×640×630mm


    Working air pressure


    0.50-0.70Mpa


    Standard working area


    110×150mm


    Fixture


    1 set


    Temperature


    0-400℃


    Temperature precision


    ±2℃


    Presssing time


    0-99S


    Thermode pressure


    0.1-0.6Mpa


    Weight


    62Kg
