Features:Laser Printer SMT Laser Marking Machine-YSL-250 fit for Smt/SMD/LED /PCBA
1. The performance of the CO2 laser, fiber laser, green laser and UV laser is stable.
2. High speed vibrating mirror is adopted,high precision,high speed,and performance is stable.
3. CCD positioning is fast and accurate, and can be automatically recognized after marking.
4. The software interface is humanized, the operation is simple and easy to learn, and the editing function is powerful.
5. Automatically read the two dimensional code and save the data.Automatically record and alarm when it is unable to read.
6. Compared with ordinary printing, no consumables, environmental pollution free, maintenance free.
7. It has the function of anti reprinting data to avoid repeated marking of information.
8. It can be seamlessly connected with SMT line and MES system.
9. Offline and online compatible.
Laser Marking System
Built-in flap ・Double-sided coding, flipping the front and back, ・Reduce transmission time and increase efficiency by 30% |
Double track carving Directly connected to the placement machine dual track (686mm track width) •Independent marking mode: simultaneous marking of AB two tracks and different models Independent transmission board, transmission time is 0 |
Double-sided marking on upper and lower heads Simultaneous marking on side A and side B Efficiency increased by 100%
|
Minimal software operation interface • YSL independent research and development • step by step program editing steps • One-click point setting ・Multi-module custom barcode editing rules |
Application Solutions |
Online |
Can be placed at the forefront of the production line. After the incoming mark is completed, it flows into the production line for follow-up operations, MES interconnection, intelligent traceability!
|
nter SMT Laser Marking Machine YSL-250 fit for Smt/SMD/LED /PCBA Manufacture Specification：
YSL-250- | ||||||||||||
Model | ||||||||||||
Repeat Positioning Accuracy | ||||||||||||
Positioning System | ||||||||||||
Code Detection System | ||||||||||||
60*40mm | ||||||||||||
300-130mm | ||||||||||||
<25mm | ||||||||||||
| ||||||||||||
L-R | ||||||||||||
Track Width Adjustment | ||||||||||||
Single laser head, double laser head | ||||||||||||
| English Uppercase lowercase.Figure,Katakana、Chinese Characters Symbol、User Save Text (Up to 50 Types) | CODE39、CODE128、ITF、NW-7、JAN(EAN)/UPC | QR Code x Micro QR Code s IQR Code s Data Matrix x GS1 Data Matrix | VEC*4、DXF、BMP、HPGL、JPEG、Al、EPS<span style="font-size:12.0pt;font-family:"color:#274266;"> | ||||||||
Smoke Treatment method | Automatic Smoke Purification System | |||||||||||
Software | ||||||||||||
Software Interface | Chinese and English optimization interface | |||||||||||
Poka-yoke Function | Automatic identification of PCB reverse/reverse/wrong materials | |||||||||||
Selective Printing | Dentify BAD MARK ,do not perform well,antomatically skip | |||||||||||
Barcode data source | SHOPFLOW,MES,IMS,PMS,Database、USB flash disk、This machine sets the bar code rule/ figure、Time serial number | |||||||||||
System Connection Function | Can connect SHOPFLOW,MES,IMS,PMS,Mapping,EAP and other management systems,Fully automated production | |||||||||||
Database | Each Model can be archived,directly tunde when generated again | |||||||||||
Engraving Angle | 0-360° | |||||||||||
Others | ||||||||||||
Voltage | 220V50/60Hz | |||||||||||
Gas source | >0.5MPa | |||||||||||
Environmental Requirement | 5~40°C ,30~80Rh | |||||||||||
Safety Precautions | 3.0KVA | |||||||||||
Equipment Weight | 1850kg | |||||||||||
Equipment size | 1700*1200*1600mm9（L/W/H） | |||||||||||
Laser specification | ||||||||||||
Laser type | Flber | UV | GR | |||||||||
Laser wavelength | 1064nm | 355nm | 532nm | |||||||||
Laser level | Class4 | Class4 | Class4 | |||||||||
Laser power | 20w/30W | 3W/5W | 10W | |||||||||
Laser spot diameter | 0.07mm | 0.04mm | 0.06mm | |||||||||
Laser cooling mode | Air cooling | Water- cooling | Water- cooling | |||||||||
Laser Irradiation Range | 150x130mm | |||||||||||
